No other light source can match the efficiency of an LED, the acronym for Light Emitting Diode. An LED generates light without UV and infra-red radiation. It also guarantees durability of 65,000 operating hours by low energy consumption and a compact style. You can quickly recoup the initial expenses. The LED projector generates less warmth and can be used absolutely noiselessly without aeration. Immediately after being switched on the light is reproduced in full intensity. The projections have the distinction of an extraordinary sharpness and an even distribution of brightness which is the result of precise emission without an additional reflector.
 |
environmentally friendly, conserves natural resources |
 |
noiseless, low heat emission |
|
 |
low energy consumption, high light-yield |
 |
mercury-free, easily recycable |
|
 |
65,000 hours lamp life, low maintenance |
 |
|||
 |
 |
 |
|
PHOS mini |
PHOS 20 |
PHOS 20 premium |
|
| LED light source: | 10W high power | 20W high power | 20W high power |
| luminous flux of the LED: | 860 Lumen | 1,700 Lumen | 1,700 Lumen |
| projection distance: | 3 m | 3 m | 3 m |
|
projection distance in darkness: |
6 m | 8 m | 8 m |
|
average lifetime of the LED: |
65,000 Hours | 65,000 Hours | 65,000 Hours |
| colour temperature: | 6,500 - 8,000 °K | 6,500 - 8,000 °K | 6,500 - 8,000 °K |
| heat sink design: | radial | radial | streamlining |
| cooling: | passive, noiseless |
passive, noiseless |
passive, noiseless |
| weatherproof: | – | – | – |
| effect options available: | – | – | – |
| changeable lens: | – | – | – |
| item number / colour: |
20001130 (silver) 20001120 (black) 20001110 (white) |
20000130 (silver) 20000120 (black) 20000110 (white) |
20000630 (silver) |
 |
|
|
 |
 |
 |
|
PHOS mini LT |
PHOS 20 LT |
PHOS 20 outdoor |
|
| LED light source: | 10W high power | 20W high power | 20W high power |
| luminous flux of the LED: | 860 Lumen | 1,700 Lumen | 1,700 Lumen |
| projection distance: | 3 m | 3 m | 3 m |
|
projection distance in darkness: |
6 m | 8 m | 8 m |
|
average lifetime of the LED: |
65,000 Hours | 65,000 Hours | 65,000 Hours |
| colour temperature: | 6,500 - 8,000 °K | 6,500 - 8,000 °K | 6,500 - 8,000 °K |
| heat sink design: | radial | radial | radial |
| cooling: | passive, noiseless |
passive, noiseless |
passive, noiseless |
| weatherproof: | – | – | yes, IP 64 |
| effect options available: | – | – | – |
| changeable lens: | – | – | – |
| item number / colour: |
20001230 (silver) 20001220 (black) 20001210 (white) |
20001430 (silver) 20001420 (black) 20001410 (white) |
20000720 (black) |
|
|
|
|
 |
 |
|
|
PHOS 40 |
PHOS 20 downlight |
PHOS 40 downlight |
|
| LED light source: |
40W high power |
20W high power |
40W high power |
| luminous flux of the LED: |
2.400 Lumen |
1,700 Lumen |
2,400 Lumen |
| projection distance: |
3.5 m |
3 m |
3.5 m |
|
projection distance in darkness: |
8 m |
6 m |
8 m |
|
average lifetime of the LED: |
50,000 Hours |
65,000 Hours |
50,000 Hours |
| colour temperature: |
6,500 - 8,000 °K |
6,500 - 8,000 °K |
6,500 - 8,000 °K |
| heatsink design: |
- |
radial |
– |
| cooling: |
active ventilation |
passive |
active ventilation |
| weatherproof: | - | – | – |
| effect options available: | - | – | – |
| changeable lens: | - | – | – |
| item number / colour: |
20002130 (silver) 20002120 (black) 20002110 (white) |
20001630 (silver) 20001610 (white) |
20001730 (silver) 20001710 (white) |
|
|
|
|
 |
 |
|
GL 60 LED |
GL 60 LED outdoor |
|
| LED light source: |
60W extreme power |
60W extreme power |
| luminous flux of the LED: |
2,900 Lumen |
2,900 Lumen |
| projection distance: |
8 m |
8 m |
|
projection distance in darkness: |
20 m |
20 m |
|
average lifetime of the LED: |
30,000 Hours |
30,000 Hours |
| colour temperature: |
6,500 - 8,000 °K |
6,500 - 8,000 °K |
| heatsink design: |
– |
– |
| cooling: |
active ventilation |
active ventilation |
| weatherproof: | – | yes, IP 23 |
| effect options available: | yes | – |
| changeable lens: |
several focal lengths are available. |
several focal lengths are available. |
| item number / colour: | 20000230 (silver-grey) | 20000830 (silver-grey) |
|
|
|
Download the current brochure PHOS LED Projectors (PDF | 933 KB)
