A compact projector with big effect
The projection motif can be changed without any tool and to bring the motif into focus the lens is turned.
|
|
|
|
|
|
|
SPECIFICATIONS |
| item: | PHOS mini |
| body: | aluminium |
| available colours: | silver, black, white |
| weight: | 1.7 kg |
| on / off switch: | - |
| environmental conditions: | for indoor use only |
| light source: | 10 W High-Power LED |
| recommended projection distance in normal room light: | 3 m |
| recommended projection distance in darkness: | 6 m |
| average lifetime of the LED: | 65,000 operating hours |
| colour temperature: | 6,500 - 8,000 °Kelvin |
| luminous flux of the LED: | 860 Lumen |
| gobo size / image size: | 37.5 mm / 20 mm |
| voltage: | 90 - 264 V AC / 47 - 63 Hz |
| active power (power consumption): | 14 W |
| apparent power: | 36 VA |
| efficiency: | 0.39 cos. Phi |
| electrical protection: | protection class I |
| item no.: |
20001130 (silver) 20001120 (black) 20001110 (white) |
Standard series with high power LED, 85 mm standard lens, mounting plate for standing or fixing to walls or ceilings, power cable with plug. The machine is ready to plug in and run. Required accessories: glass gobo with individually designed motif.
PHOS mini specification sheet (PDF | 214 KB)
PHOS mini operating instructions (PDF | 1070 KB)
Brochure PHOS LED Projectors (PDF | 933 KB)
