Extreme-Power LED Projection System for outdoor use
The luminosity of the GL 60 LED projector matches that of a 200 watt metal halide lamp. The weather-protected device is ready for outdoor use.
|
|
SPECIFICATIONS |
| item: | GL 60 LED outdoor |
| body: | aluminium |
| available colour: | silver-grey |
| weight: | 8.1 kg |
| on / off switch: | – |
| environmental conditions: | for outdoor use |
| light source: | 60 W Extreme-Power LED |
| recommended projection distance in normal roomlight: | 8 m |
| recommended projection distance in darkness: | 20 m |
| average lifetime of the LED: | 30,000 operating hours |
| colour temperature: | 6,500 - 8,000 °Kelvin |
| luminous flux of the LED: | 2.900 Lumen |
| gobo size / image size: |
50 mm / 32 mm from 19 Februar 2015, |
| voltage: | 220-240 V AC / 50-60 Hz |
| active power (power consumption): | 92 W |
| apparent power: | 159 VA |
| efficiency: | 0.58 cos. Phi |
| electrical protection | protection class I |
| ingress protection rating: | IP 23 |
| changeable lens: | yes, several focal lengths are available |
| lighting effects available: | – |
| connectors for lighting effects: | 1 x 12 V AC |
| item number: | 20000830 (silver-grey) |
Standard series with extreme power LED, 85 mm waterproof standard lens, power cable with plug. The machine is ready to plug in and run. Required accessories: glass gobo with individually designed motif.
(using Standard Lens f=85mm)
GL 60 LED outdoor Specification Sheet (PDF | 138 KB)
GL 60 LED Instruction Manual (PDF | 183 KB)
Brochure PHOS LED Projectors (PDF | 933 KB)
