Extreme Power LED Projection Systems
The luminosity of the GL 60 LED projector matches that of a 200 watt metal halide lamp.
|
|
SPECIFICATIONS |
| item: | GL 60 LED |
| body: | aluminium |
| available colour: | silver-grey |
| weight: | 2.95 kg |
| on / off switch: | on the back side of the device |
| invironmental conditions: | for indoor use only |
| light source: | 60 W Extreme-Power LED |
| recommended projection distance in normal room light: | 8 m |
| recommended projection distance in darkness: | 20 m |
| average lifetime of the LED: | 30,000 operating hours |
| colour temperature: | 6,500 - 8,000 °Kelvin |
| luminous flux of the LED: | 2,900 Lumen |
| gobo size / image size: |
50 mm / 32 mm 70 mm / 32 mm until February 2013 |
| voltage: | 90-120 V or 220-240 V AC / 50-60 Hz |
| active power (power consumption): | 90 W |
| apparent power: | 150 VA |
| efficiency: | 0.6 cos. Phi |
| electrical protection: | protection class I |
| changeable lens: |
yes, several focal length available |
| lighting effects available: | yes, several lighting effects available |
| connectors for lighting effects: | 2 x 12 V AC |
| item number: | 20000230 (silver-grey) |
Standard series with extreme power LED, 85 mm standard lens, power cable with plug. The machine is ready to plug in and run. Required accessories: glass gobo with individually designed motif.
(using Standard Lens f=85mm)
GL 60 LED Specification Sheet (PDF | 125 KB)
GL 60 LED Instruction Manual (PDF | 187 KB)
Brochure PHOS LED Projectors (PDF | 933 KB)
